Description
Overview
DIN7 specifies the dimensional requirements for parallel pins, ensuring reliable interchangeability and engineering performance.
This selected size is specified with diameter M5, thread M5.
Sold per piece. Screwman code CCHT514H.
Material, Grade & Strength
Select the material and grade according to the intended load, environment and application.
Finish & Corrosion Protection
Plain finish is intended for protected indoor applications.
Typical Uses
Used in machinery, maintenance, manufacturing, agriculture, mining and general engineering applications.
Technical Tips
- Select the correct size and material for the application.
- Inspect components before installation.
- Follow recognised engineering practices and manufacturer recommendations.
Data Sheet
Technical Drawing – DIN 7991
Dimension symbols refer to the table below. Drawing source: Fabory data sheet 07470.
Specifications
| Measurement Type | Metric |
|---|---|
| Thread Size | M5 |
| Thread Style | Fully Thread |
| Drive Type | Hex |
| Head Style | Round |
| Diameter | M5 |
| Material | Hi - Tensile Steel |
| Finish | Plain |
| Grade | Grade 10.9 |
| Standards Met | DIN 7991 |
| Package Quantity | 1 |
| Package Type | Box |
