Description
Overview
DIN7 specifies the dimensional requirements for parallel pins, ensuring reliable interchangeability and engineering performance.
This selected size is specified with diameter M2.5, length 8 mm, thread M2.5, pitch 0.45 mm.
Sold in multiples of '200 pieces. 1 Box = '200 pieces.
Material, Grade & Strength
A2 (304) stainless steel provides excellent corrosion resistance.
Finish & Corrosion Protection
Match the finish to the service environment.
Typical Uses
Used in machinery, maintenance, manufacturing, agriculture, mining and general engineering applications.
Technical Tips
- Select the correct size and material for the application.
- Inspect components before installation.
- Follow recognised engineering practices and manufacturer recommendations.
Data Sheet
Technical Drawing – DIN 7991
Dimension symbols refer to the table below. Drawing source: Fabory data sheet 01000.
Specifications
| Measurement Type | Metric |
|---|---|
| Thread Size | M2.5 |
| Thread Style | Fully Thread |
| Drive Type | Hex |
| Head Style | Countersunk |
| Diameter | M2.5 |
| Length | 8 mm |
| Material | Stainless Steel |
| Finish | Stainless steel |
| Grade | Grade (A2) |
| Standards Met | DIN 7991 |
| Package Quantity | 1 |
| Package Type | Box |
