DIN7 specifies the dimensional requirements for parallel pins, ensuring reliable interchangeability and engineering performance.
This selected size is specified with diameter M2, length 4 mm, thread M2.
Sold per piece. Screwman code CAPTSS24H.
Material, Grade & Strength
Select the material and grade according to the intended load, environment and application.
Finish & Corrosion Protection
Plain finish is intended for protected indoor applications.
Typical Uses
Used in machinery, maintenance, manufacturing, agriculture, mining and general engineering applications.
Technical Tips
- Select the correct size and material for the application.
- Inspect components before installation.
- Follow recognised engineering practices and manufacturer recommendations.
Technical Drawing – DIN 7984
Dimension symbols refer to the table below. Drawing source: Fabory data sheet 07105.
Specifications
| Measurement Type | Metric |
|---|---|
| Thread Size | M2 |
| Thread Style | Partial Thread |
| Drive Type | Hex |
| Head Style | Cap |
| Diameter | M2 |
| Length | 4 mm |
| Material | Hi - Tensile Steel |
| Finish | Plain |
| Grade | Grade 12.9 |
| Standards Met | DIN 7984 |
| Package Quantity | 1 |
| Package Type | Box |
