Description
Overview
Flat Washers Form A to DIN 125, NYLON, size M2.
Sold per piece. Screwman code NFW2H.
Finish & Corrosion Protection
Plain / self colour. No applied coating. Stainless, brass and nylon parts are supplied plain; plain steel parts need oil, paint or protected environments.
Dimensions – DIN 125 A / ISO 7089 M2
| Standard | DIN 125 A / ISO 7089 |
|---|---|
| Product | Flat washer, form A |
| Nominal size | M2 |
| Inside diameter (d1) | 2.2 mm |
| Outside diameter (d2) | 5 mm |
| Thickness (h) | 0.3 mm |
| Weight (calculated) | 0.01 kg per 1 000 pieces |
Material, Grade & Strength
| Material | Nylon 6.6 |
|---|
Finish & Corrosion Protection
Plain / self colour: No applied coating. Stainless, brass and nylon parts are supplied plain; plain steel parts need oil, paint or protected environments.
DIN 125 A data sheet – all sizes
| Size | Nominal size | Inside diameter (d1) | Outside diameter (d2) | Thickness (h) |
|---|---|---|---|---|
| M2 | M2 | 2.2 mm | 5 mm | 0.3 mm |
| M2.5 | M2.5 | 2.7 mm | 6 mm | 0.5 mm |
| M3 | M3 | 3.2 mm | 7 mm | 0.5 mm |
| M4 | M4 | 4.3 mm | 9 mm | 0.8 mm |
| M5 | M5 | 5.3 mm | 10 mm | 1 mm |
| M6 | M6 | 6.4 mm | 12 mm | 1.6 mm |
| M8 | M8 | 8.4 mm | 16 mm | 1.6 mm |
| M10 | M10 | 10.5 mm | 20 mm | 2 mm |
| M12 | M12 | 13 mm | 24 mm | 2.5 mm |
| M14 | M14 | 15 mm | 28 mm | 2.5 mm |
| M16 | M16 | 17 mm | 30 mm | 3 mm |
| M18 | M18 | 19 mm | 34 mm | 3 mm |
| M20 | M20 | 21 mm | 37 mm | 3 mm |
| M22 | M22 | 23 mm | 39 mm | 3 mm |
| M24 | M24 | 25 mm | 44 mm | 4 mm |
| M27 | M27 | 28 mm | 50 mm | 4 mm |
| M30 | M30 | 31 mm | 56 mm | 4 mm |
| M33 | M33 | 34 mm | 60 mm | 5 mm |
| M36 | M36 | 37 mm | 66 mm | 5 mm |
| M39 | M39 | 40 mm | 72 mm | 6 mm |
| M42 | M42 | 43 mm | 78 mm | 7 mm |
| M45 | M45 | 46 mm | 85 mm | 7 mm |
| M48 | M48 | 50 mm | 92 mm | 8 mm |
Nominal dimensions per DIN 125 A / ISO 7089. Weights are calculated from nominal dimensions and are a guide only (±10%). Values for fit and strength should be confirmed against the standard for critical applications.
