Shield (sleeve) anchor, loose bolt type, Steel, size M10.
Sold per piece. Screwman code RAW10H.
Description: SHIELD ANCHOR MILD STEEL 4.8 M 10
Dimensions – Shield (sleeve) anchor, loose bolt type M10
| Standard | - |
|---|---|
| Product | Shield (sleeve) anchor, loose bolt type |
| Bolt thread | M10 x 1.5 |
| Drill diameter | 16 mm (typical) |
Material, Grade & Strength
| Material | Carbon steel |
|---|
Finish & Corrosion Protection
Plain / self colour: No applied coating. Stainless, brass and nylon parts are supplied plain; plain steel parts need oil, paint or protected environments.
Shield (sleeve) anchor, loose bolt type data sheet – all sizes
| Size | Drill dia |
|---|---|
| M6 | 12 mm |
| M8 | 14 mm |
| M10 | 16 mm |
| M12 | 20 mm |
| M16 | 25 mm |
Nominal dimensions per Shield (sleeve) anchor, loose bolt type. Weights are calculated from nominal dimensions and are a guide only (±10%). Values for fit and strength should be confirmed against the standard for critical applications.
